3600 Lumens; 120g Lamp; Bluetooth; 6.9 Ah SmartCore Battery; Runtime 1:45-160 Hours; 430g Total System Weight


THE NIGHT-TIME GAME-CHANGER. Boasting an astonishing 3600 lumens, the redesigned Wilma Headlamp is brighter than conventional car headlights. CNC-machined from a single piece of high-quality, lightweight aluminum, Wilma is now even more robust, more beautiful and above all more functional. Integrated Bluetooth control makes Wilma R X7 the ideal companion for trail-running, cross-country-skiing, mushing and hiking. SYSTEM INCLUDES: Wilma R 3600 Lumen LED Lamp head, 6.9 Ah SmartCore battery, Headband, Bluetooth Remote, Bluetooth Remote Armlet Mount, 120 cm extension cord, Wiesel V4 charger, Pouch M, and manual.

SKU: 1650-002 Categories: ,

Full Description

Innovative German manufacturing packs high-end LED technology into Wilma’s robust, sleek and functional aluminum housing, which is milled from a single piece of high-end, lightweight aluminum. Intelligent electronics and more cooling fins prevent overheating.

Wilma’s powerful illumination, paired with a perfectly balanced luminous image, allows you to indulge in any activity at night, no matter how extreme or technical it is. So test your limits while mushing or make the run of your life while skiing. Wilma knows no limits.

Our lightweight headband, crafted from high-quality flexible textiles, offers long-lasting comfort, a secure fit and reliable durability in any weather condition. In addition to quality, we’ve designed our headbands to provide the perfect balance between battery and lamphead to evenly distribute weight on the head for comfort.

The lamphead is securely fixed with two screws, but is adjustable horizontally as well. Headband size can be adjusted for the perfect fit and can be worn over a cap.

Wilma offers 10 different dimming levels and numerous additional functions, such as SOS, FLASH, RVLR and the alpine emergency signal modes, for maximum safety and versatility.

With a single keystroke, you can switch between levels, easily check the remaining battery life or combine up to four light levels in any order to create your own light program.

Our intelligent SmartCore electronics pull power evenly from Li-ion battery cells, minimizing burnout and maximizing the longevity of your battery. The battery also acts as a capacity gauge, offering visual and audio signals in 10% increments.

Our long-lasting Li-Ion SmartCore batteries are waterproof and feature a robust protective outer shell made of ABS plastic and designed to resist extreme weather, shocks and mud.Integrated electronics prevent electric faults on rough terrain.

Wilma R has an integrated Bluetooth module that allows easy control of up to 10 preprogrammed light modes directly from the handlebar — with lightning speed, without delay, without cable and without security risk.

The LUPINE LIGHT CONTROL APP for iOS and Android makes it possible to adjust the brightness levels and get unique status information from a smartphone.



Lupine products are made in Germany and are backed by more than 20 years of precision manufacturing and high-tech innovation.

We are one of the best in the industry in the areas of:

  •  System weight-to-lumen output ratio
  •  Price-to-lumen output ratio
  •  Warranty

We take pride in our customer support and service team that can service your light directly at our Pennsylvania location.

Product Details


The FL1 standard is a set of ANSI / NEMA standards to compare the product specifications of different lamp manufacturers.


Runtime Chart for Wilma R X 7 with 6.9 Ah SmartCore Battery

28 W/ 3600 Lumens 1:45 Hours

23 W / 2700 Lumens – 2:00 Hours

19 W / 2300 Lumens – 2:30 Hours

14 W / 1800 Lumens – 3:20 Hours

10 W / 1350 Lumens – 4:45 Hours

7 W / 1000 Lumens –  6:45 Hours

5 W/ 750 Lumens –  9:30 Hours

3 W / 450 Lumens – 15:00 Hours

1.5 W / 225 Lumens – 31:00 Hours

0.3 W / 45 Lumens – 150:00 Hours


Wilma R X7 3600 Lumen Headlight- 28W

Bluetooth Technology – yes

Bluetooth Remote –  Bluetooth remote switch; App available

Light Output – 3600 Lumens

Runtime – 1:45 – 160 hours

Reach FL – 1325 m

Battery – 6.9 Ah SmartCore

Weight – 430g

Battery Setup – In pocket or in backpack


Wilma R 3600 Lumens – 28W Lamphead

Bluetooth Technology – yes

Lumens – 10 steps from 0.3W (45 Lumens) to 28W (3200 Lumens)

Special Modes – Flash, SOS, Alpine emergency signal, RVLR

Material – CNC-machined, Aluminum 6061-T6, Shot-peened, Hard-anodized

Weight – 120g

Dimensions – 50 x 50mm

Protection class – IP 68 (Water tightness), IK 09 (impact strength)

Lens – 22° Optics (Collimated Lens Technology)

Illuminant – 4 Cree XM-L2 U4

LED-Board – Copper

Color Temperature – 6000K (5% tolerance)

Microprocessor – 14-bit RISC (4-Fach PLL)

Converter Phase – 50KHz

Corespeed – 32MHz

Conducting path structure – smaller 0.3 mm

Temperature control – active

Ambient Temperature –  minus 25°C to + 70°C

LED indicator – 5 x RGB LED Osram

LED Backlight – 2 x RGB LED Avago

Voltage Indicator – by RGB LED

Low-Battery warning lamphead – by backlight

Discharged capacity – by RGB LED

Reserve tank – depending on battery and type of use

Candlelight function – 0.3W

Connection cable – ULT- Ultra Low Temperature (-40° to +80° C)


Battery: SmartCore 6.9 Ah

Battery: SmartCore 6.9Ah

Material Casing: Polyamide, layer polyurethane

Battery: 7.2V6.9AAh

Watt hours: 25Wh

Weight: 240g

Proper for: all Lupine Lights

Protection class: IP 68 (waterproofness), IK 09 (impact strength)

Cell type: Panasonic NCR18650B

High current: 6C


Charger: Wiesel V4

Charge current: 0.1 – 1.2A

Input voltage: 100 – 240V

Frequency: 50- 60Hz

Display: charging control via 1 LED

Compatible batteries: Lupine Li-Ion Batteries – 7.2V

Functions: Li-Ion Charge

Microprocessor controlled: yes



Lupine’s compatible and interchangeable accessories and mount kits allow you to easily transform your Wilma lam head into a lamp for any activity.

  • VENTED HELMET – Securely mount Wilma to a vented bike helmet using the Wilma Helmet Mount and state-of-the-art Lupine hook-and-loop fastener straps.
  • HANDLEBARS – Add a Quick-Release Handlebar Mount to your Lupine system to easily secure your Wilma to mountain bike or road bike handlebars. Or use the GoPro Adapter to turn your GoPro mount into a mount for your Lupine Light — a great option for mounting your light to bike handlebars or helmets. Add a Peppi V5 Bluetooth Remote Button Mount to attach your Bluetooth button to your handlebars.
  • BATTERY MOUNT  – Use hook-and-loop fastener straps or an Endure Top Tube Case to mount your SmartCore Battery to your bike frame.
  • CHARGING STATION – Wilma’s battery is compatible with the UBS ONE Adapter, which can turn your Lupine System into a charging station for any USB device, including smartphones. A great accessory for camping and traveling!
